HP3318
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nulla accumsan felis magna, vel feugiat velit aliquet id. Sed iaculis odio pharetra vulputate efficitur. Etiam felis odio, auctor eget vehicula id, condimentum eu nisl. Vestibulum ornare efficitur lorem nec convallis.
Model:
HP3318Max. cutting length:
3300mmNet weight:
14300kgMax. cutting thickness:
100mmMain saw blade:
Φ380mm(option450mm)Main saw shaft diameter:
Φ75mmMain saw shaft rotation speed:
4000rpmScoring saw blade diameter:
Φ200mmScoring saw shaft diameter:
Φ50Scoring saw shaft rotation speed:
5200rpmSaw carriage forward speed:
0-100m/minSaw carriage backward speed:
0-120m/minMain saw motor power:
18.5kw*2scoring saw motor power:
2.2kw*2Saw carrier driving motor power:
2kw*2 ( AC sevro )Automatic feeding motor:
2kw*2 ( AC sevro )High-pressure blower motor:
3kw*2+2.2kwSide aligner motor:
0.25kwLifting platform motor:
2kwConveyor motor:
0.75kw*2Total power:
61.35kwAutomatic Feeding speed:
85m/minAir pressure:
5-7kg/cm²Worktable height:
960mmMachine size:
8000*11600*2200mmAir floating table quantity:
2Date:
23 May 2026
